Groundnut sheller
Our peanut sheller or groundnut shelling machine is produced according to the national standards strictly,it consists of rasp bar, intaglio, fan, stake,gravity separator and a second bucket etc. This groundnut sheller frame is made of high quality steel and the shelling chamber is made of stainless steel.
| Model |
6BHD-600 |
6BHD-800B |
6BHD-850B |
| Capacity(kg/hr) | 600 | 800 | 1200 |
| Power(KW) | 2.2 | 3.5 | 5 |
| Shelling rate | ≥98% | ≥98% | ≥98% |
| Breaking rate | ≤3.5% | ≤3.5% | ≤3.5% |
| Losing rate | ≤0.5% | ≤0.5% | ≤0.5% |
| Cleaning rate | ≥98% | ≥98% | ≥98% |
| Weight(KG) | 120 | 160 | 300 |
Our peanut sheller or groundnut shelling machine is produced according to the national standards strictly,it consists of rasp bar, intaglio, fan, stake,gravity separator and a second bucket etc. This groundnut sheller frame is made of high quality steel and the shelling chamber is made of stainless steel. This groundnut shelling machine has a compact structure, easy operation and reliable performance.This peanut shelling machine is used to shell peanut; can separate shells and kernels with high-efficiency and almost without damage to the kernels; the shelling rate can be ≥98%, the breaking rate is ≤3.5%, but loss rate is ≤0.5%. While peanut kernels are used for food or the raw materials for the oil mill, the shell can be used to make wood pellets or charcoal briquettes for fuel.
After starting, the shells of peanut are shelled by the rolling force between the rotating rasp bar and the fixed intaglio, and then shells and kernels fall through the grid mesh down to the air duct, and the fan blows shells out. The kernels and the unshelled small peanut fall into the gravity separator. The separator kernels are sent upward to the outlet and the separated unshelled small groundnuts are sent downwards to the elevator, and the elevator sends the unshelled groundnut to the fine grid mesh to be shelled again until the whole batch of peanut is all shelled.
